NV32-SV 3P 100MA Mitsubishi Electric Earth Leakage Circuit Breake

NV32-SV 3P 100MA  Mitsubishi Electric Earth Leakage Circuit Breake

• NV32-SV / NV32-SVF: The specific model series belonging to the WS-V class. The "S" signifies standard type performance, and "V" refers to the WS-V generation.
• 3P: 3-Pole configurations. It is designed for three-phase electrical systems.
• 100MA: 100mA rated residual operating current (earth-leakage sensitivity). Some models offer selectable 100/200/500mA leakage thresholds.

• Primary Function: Protects personnel against electric shocks and prevents electrical fires due to ground faults.
• Compact Design: Features an ultra-compact body size to minimize enclosure space.
• Voltage Rating: Operates universally across AC 100V to 440V distribution networks.
• Breaking Capacity: Provides standard 5 kA ultimate/service breaking capacity (\(I_{cu}/I_{cs}\)) at 400V AC systems.
• Compatibility: Standardized for 35mm IEC DIN rail mounting and features IP20 terminal finger protection.
