Omron NX-ECS112 SSI Module

Omron Synchronous Serial Interface (SSI) NX-ECS112 Encoder Input Motion Control Module, EIA standard RS-422-A, 32 bits max data length, Screwless push-in connector, 12 mm wide

Specification/Additional Details

• Model Name/Number : NX-ECS112
• Type of module : Encoder input
• Digital input type : SSI encoder
• Signal processing : Free running, Synchronous
• Max. encoder input frequency : 2000 kHz

• I/O connection type : Push-in

• Number of I/O connectors : 1

• Degree of protection : IP20
