NXB-125A 3P Chint MCB
Key Specifications

• Poles: 3P (3-Pole for three-phase AC circuits)
• Rated Current: 63A, 80A, 100A, or 125A option
• Rated Operational Voltage: 400V AC (2P–4P systems)
• Frequency: 50/60 Hz
• Tripping Curves: C curve (thermal-magnetic release at 8In) or D curve (12In)
• Rated Short-Circuit Breaking Capacity (\(I_{cu}\)): 10 kA
• Service Breaking Capacity (\(I_{cs}\)): 7.5 kA
• Rated Impulse Withstand Voltage (\(U_{imp}\)): 4 kV
• Compliance Standards: IEC/EN 60947-2

Core Functions

• Overload & Short-Circuit Protection: Automatically disconnects current when faults or dangerous overloads occur.
• Positive Isolation: Clear indication of contact status for safe maintenance.
• Mechanical & Electrical Life: Rated for 20,000 mechanical cycles and 4,000 to 6,000 electrical cycles.
