IFM 01D105 01DLF3KG Laser Distance Sensor

IFM 01D105 01DLF3KG Laser Distance Sensor O1D105 O1DLF3KG Background Suppression, 18 to 30V DC Operating Voltage, 0.2 to 10m Operating Distance, PNP Output, 200 mA max. Output Current,Output Function : NO/NC programmable; 4-20 mA or 0-10 V, Laser (red light), 650 nm Wavelength, Light spot 15mm (at range 10 m), LED Indication (4-digit) Function Display

Specification/Additional Details

• Distance range : 10m
• Brand : IFM
• Model : O1D105 O1DLF3KG
• Operating Voltage : 18V to 30V DC
• Output Type : PNP
• Output current max. : 200 mA

• Output function : NO/NC programmable; 4-20 mA or 0-10 V

• Operating distance : 0.2-10 m

• Type of light : Laser (red light)

• Transmission type : COM 2 (38.4 kBaud)

• Wavelength : 650 nm

• Short-circuit protection : yes

• Reverse polarity protection : yes

• Light spot : 15mm (at range 10 m)

• Adjustment : Buttons

• Function display : LED indication (4-digit)

• Connection : Connector M12 (5 pole)

• Housing material : Diecast zinc

• Protection rating : IP67

• Interfaces : IO-Link

• Laser protection class : II

• Special features : Background suppression
