O6T204 IFM Sensor

O6T204 IFM Sensor
Key Specifications

• Sensing Range: 5 mm to 500 mm (adjustable via a potentiometer).
• Electrical Design: NPN output with a selectable light-on or dark-on mode.
• Operating Voltage: 10 to 30 V DC.
• Switching Frequency: 1000 Hz.
• Light Type: Visible red light with a wavelength of 633 nm.
• Protection Rating: IP 65 and IP 67, ensuring resistance to dust and water.
• Connection: 2-meter PUR cable with a 3-wire configuration.
• Housing Material: Robust construction using ABS and PPSU materials.

Core Features

• Intuitive Setup: Features a potentiometer for quick range adjustments and a rotary switch for selecting the output mode.
• Visual Indicators: Equipped with two highly visible LEDs—one green for power/operation and one yellow to indicate the switching status.
• Robust Design: Engineered for harsh industrial environments, with a high mean time to failure (MTTF) of approximately 897 years.
