Omron D4SL-N4RFG-D Guard Lock Safety-Door Switch

Name: Omron D4SL-N4RFG-D Guard Lock Safety-Door Switch
Brand: QYSMT
Availability: InStock

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

Product variants

Quantity

Technical Specifications

Manufacturer / Series: omron D4SL-N Series

Operation Type: Power-to-lock, spring-released solenoid mechanism

Contact Configuration: 3 Normally Closed (NC) door contact + 3 Normally Closed (NC) lock monitor contact

Solenoid Voltage: 24 VDC

Holding Force: 1,300 N (approx. 292 lbf / 132 kgf)

Enclosure Rating: IP67 (dust tight and protected against temporary water immersion)

Conduit / Termination: M20 conduit size with a terminal block connection

Core Features

Safety Compliance: Designed for machine safety gates and automated industrial cells to prevent access until hazards subside.

Status Feedback: Integrated LED indicator provides immediate visual confirmation of lock and power status.

Flexible Mounting: Compact resin body allows head orientation changes without detac
