EE-SX672-WR 1M Open Slot Photo Sensor 5MM NPN

EE-SX672-WR 1M Open Slot Photo Sensor 5MM NPN, EE-SX672-WR Photo Microsensor EESX672WR, EE-SX672-WR EESX672WR Sensor with 1M Cable

The EE-SX672-WR is an Omron Automation and Safety T-shaped, slot-type photo microsensor with a 5 mm sensing distance. It is designed for precise object detection in industrial applications.

Key specifications

• Sensing method: Through-beam with a slot.
• Sensing distance: 5 mm.
• Shape: T-shaped.
• Output configuration: NPN open collector.
• Operating mode: Selectable Dark-ON/Light-ON.
• Light source: Infrared LED (940 nm peak wavelength).
• Supply voltage: 5 to 24 VDC.
• Output current: Up to 100 mA.
• Connection method: Pre-wired models with a 1m robot cable are designated EE-SX672-WR 1M.
• Response frequency: 1 kHz minimum.
• Enclosure rating: IP50.
• Operating temperature: -25 to +55°C.

Product features

• Compact design: The sensor features a compact, integrated emitter and receiver in a single housing.
• Selectable output: The Dark-ON/Light-ON operation is selectable by wiring, providing flexibility.
• High response frequency: The fast response time allows for detection in high-speed applications.
• Durable cable: Models with a "WR" suffix include a flexible robot cable for enhanced durability.
