Omron ZX-LDA41-N 2M Photoelectric Sensor

Omron ZX-LDA41-N 2M Photoelectric Sensor
Core Technical SpecificationsThe amplifier processes physical measurements from the laser head and translates them into readable metrics or actionable digital output

• Output Type: PNP Transistor Output (High/Pass/Low comparison outputs) along with a selectable voltage/current linear output.
• Operating Voltage: 12 to 24 VDC (±10% ripple).
• Measurement Period: Super-fast sampling at 150 μs.
• Averaging Capabilities: Selectable average count settings from 1 up to 4,096 to smooth out signals and reduce noise.
• Connection Method: Pre-wired 2-meter cable model for system integration.
• Physical Housing: Durable Polybutylene Terephthalate (PBT) casing with a Polycarbonate cover, designed for standard DIN-rail mounting.

How the System Works

1. The Sensor Head: A separate laser head (such as the diffuse reflective ZX-LD40 or through-beam models) projects a laser beam onto the target.
2. The Amplifier (ZX-LDA41-N): The sensor head plugs directly into this amplifier. The amplifier calculates the exact position or displacement using its dual digital display.
3. Smart Functions: It includes useful maintenance features, such as displaying a laser diode deterioration warning on the sub-display so you can replace the laser head before a total failure occurs.
