OVEL-10-H-15-PQ-VQ6-UA-C-A-V1PNLK-H3 FESTO Vacuum generator

Name: OVEL-10-H-15-PQ-VQ6-UA-C-A-V1PNLK-H3 FESTO Vacuum generator
Brand: QYSMT
Availability: InStock

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

Product variants

Quantity

Feature	Specification Details
Nominal Size (Laval Nozzle)	0.95 mm
Grid Dimension	15 mm
Maximum Suction Flow Rate	21 l/min
Maximum Vacuum Capacity	92%
Operating Pressure	2 bar to 7 bar
Max. Input / Vacuum Pressure	4 bar / 3.8 bar
Electrical Connection	3-pin 2.5m pre-wired cable with bare flying leads
Control / Supply Voltage	24 VDC nominal (21.6V to 26.4V)
Pneumatic Port 1 (Inlet)	6 mm push-in sleeve
Vacuum Port	QS-6 (6 mm push-in fitting)
Silencer Design	Open silencer
Switching Output	PNP / NPN (Switchable) + IO-Link functionality
Degree of Protection	IP40

Key Features & Benefits

Smart Monitoring: Features a built-in piezoresistive sensor with a 2-digit LED display to monitor real-time vacuum pressure ranges (-1 bar to +1 bar).
IO-Link Enabled: Supports IO-Link protocols for straightforward parameter assignment, diagnostics, and seamless integration into automated factory setups.
Rapid Cycle Times: Employs a second built-in solenoid valve to generate an adjustable ejector pulse, rapidly reducing the vacuum to drop handled parts instantly.
Low Noise Fatigue: Uses an integrated open silencer that limits audible noise to just 68 dB(A) during operation.
Space-Saving Footprint: Built with a 15mm grid width housing made from reinforced polyamide nylon, keeping overall unit weight under 1 lb
