Spring Test Probe Flat Round Head P156-G Pogo Pin
The P156-G Pogo Pin is a spring-loaded test pin featuring a flat round tip, commonly used for testing printed circuit boards (PCBs) and creating momentary electrical connections in jigs and fixtures.
Product specifications
- Model: P156-G
- Head type: Flat round
- Total length: 34 mm
- Tube diameter: 2.36 mm
- Pin diameter: 2.0 mm
- Full stroke: 6.5 mm
- Travel: 4 mm
- Rated current: 3A
- Spring pressure: 250 g
- Color: Gold-plated
- Construction material: Brass
Common applications
P156-G pogo pins are designed for use in various testing and production environments.
- PCB testing: Used in test fixtures to make connections with test pads and holes for quick testing of circuit boards.
- Production jigs: Enables quick programming and testing of components without the need for permanently soldered headers.
- Burn-in testing: Ensures reliable and consistent electrical connections for long-duration testing.
- Data writing: Used for programming and writing data to electronic devices.
- JTAG programming: Allows for in-circuit programming of a board when soldering is not an option.
