Spring Test Probe P75-1D Pogo Pin
Pogo Pin PA160-G2 Probe Spring Test Needle Outer Diameter 1.02 mm, Round Head 1.0 mm, Total Length 16.5 mm
The P75-1D is a spring-loaded pogo pin, used for making temporary electrical connections in testing jigs and for connecting components on a printed circuit board (PCB). It is part of the broader P75 series of test probes.
Specifications
| Feature | Specification |
|---|---|
| Body Diameter | 1.02 mm |
| Total Length | 16.5 mm |
| Head Diameter | 1.0 mm (round head) |
| Current Rating | 3A |
| Full Stroke | 2.50 mm |
| Spring Pressure | 100g |
| Plunger Material | Heat-treated beryllium copper |
| Barrel Material | Phosphor bronze |
| Plating | Gold plated |
Common applications
P75-1D pogo pins and other spring-loaded probes are used in a variety of electronics applications:
- Creating PCB test jigs: The spring-loaded mechanism provides a solid, repeatable connection for quickly testing PCBs without needing to solder.
- Device programming: Pins can be inserted into a programming cable to make temporary connections for programming microcontrollers on boards.
- Modular electrical connections: These pins are used for board-to-board connections where repeated mating and un-mating are required, such as in docking stations for chargers or data transfer.
- Prototypes: They are handy for testing prototypes or making quick, solid electrical connections for experimentation.
