Spring Test Probe Flat Head P75-G2 Pogo Pin
Pogo Pin P75-G2 Probe Spring Test Needle Outer Diameter 1.02MM, P75-G2 Test Needle Flat Head 1.3 mm Tip Total length 16.5mm
The P75-G2 is a spring-loaded test probe, or pogo pin, used for creating reliable, temporary electrical connections in various applications, particularly for printed circuit board (PCB) testing. It features a "flat" or "concave head" plunger and is part of the P75 series of spring test probes.
Specifications
- Overall length: 16.50mm
- Needle diameter: 1.02mm (outer barrel diameter)
- Needle bar diameter: 0.74mm (plunger diameter)
- Needle head diameter: 1.30mm
- Full stroke: 2.50mm
- Spring pressure: 100g
- Current rating: 3A
- Current resistance: 50mΩ
- Recommended drilling size: 1.4mm
- Minimum test spacing: 1.91mm
Construction materials
- Plunger: Heat-treated beryllium copper
- Barrel: Gold-plated phosphor bronze
- Spring: Gold-plated music wire
- PCB testing jigs: Making quick electrical connections to test pads and holes on circuit boards during production.
- Device programming: Creating temporary connections for programming circuits without the need for soldered headers.
- Other test fixtures: Anywhere a reliable, spring-loaded contact is needed for temporary electrical connections
