Spring Test Probe Star-shaped Crown Head P75-LM2 Pogo Pin

Pogo Pin P75-LM2 Star-shaped Head Probe Spring Test Needle Outer Diameter 1.02MM, P75-LM2 Test Needle Crown Head 1.3 mm Tip Total length 16.5mm

The P75-LM2 is a spring-loaded test probe, or pogo pin, commonly used in electrical and PCB testing. The "LM2" designation refers to its star-shaped (LM head type) tip design, which is adapted for testing against through-holes and finger pads. These probes are typically gold-plated for superior conductivity.

Specifications

• Head Type: Star-shaped (LM head type)
• Needle Total Length: ~16.5 mm
• Needle Diameter: ~1.02 mm
• Receptacle Diameter: ~1.32 mm (sold separately)
• Full Stroke: 2.50 mm
• Spring Pressure: 100g
• Current Rating: 3A
• Current Resistance: 50 mΩ
• Materials: Gold-plated beryllium copper plunger and music wire spring, with a gold-plated phosphor bronze barrel.
