Spring Test Probe PA02-B1 Pogo Pin
Gold plated Tip Test Probe PA02-B1 Pogo Pin PCB test Probe spring test probe PA02-B1 Test pin, PA02-B1 Needle gold plated tip Pogo pin
The PA02-B1 is a spring-loaded test probe, also known as a pogo pin, used primarily for testing printed circuit boards (PCBs). The "B1" designation refers to its specific needle head type, which is a pointed tip designed for making contact with guide pins, solder joints, or through-hole components.
Key specifications
- Needle Tip: A 45° pointed/spear tip, designated "B1," which can puncture contaminated layers on a circuit board.
- Compatibility: The probe is inserted into a receptacle (such as an R50 series socket) which allows for easy replacement without resoldering.
- Application: It is used for conductive testing to ensure the stability and durability of electronic components and connections.
- In-Circuit Testing (ICT): For high-volume testing of assembled PCBs to check for shorts, opens, and component values.
- Functional Testing: To connect test jigs and fixtures to the board to verify its functional performance.
- Programming Jigs: To temporarily connect programming hardware to a circuit board without soldering.
- Connecting PCBs: Pogo pins can serve as a temporary or modular connection between two circuit boards, especially in situations with high tolerances or blind mating.
