Spring Test Probe PA02-H2 PCB Test Probe

Thimble spring conductive needle PA02-H2 PCB test needle nine-claw plum blossom, 0.68MM Test Probe PA02-H2 Nine-Jaw Plum Blossom Head Test Probe

The PA02-H2 is a specific model of spring test probe, also known as a pogo pin, used for testing printed circuit boards (PCBs). It features a distinctive nine-claw "plum blossom" head, designed for testing solder joints and pads.

• Head type: Nine-claw or "plum blossom" head.
• Needle diameter: 0.90 mm.
• Shank diameter: 0.68 mm.
• Overall length: 24.7 mm.
• Material: Copper with gold-plated heads to ensure high conductivity and resistance to corrosion, which is crucial for maintaining accuracy over many test cycles.

• PCB testing: It is an essential component for In-Circuit Testing (ICT) and Functional Circuit Testing (FCT) of PCBs.
• Solder joint testing: The nine-claw head is specifically designed to make reliable contact with solder joints and pads, even if they are contaminated.
• High accuracy: Due to precise computer machining, these probes have very high dimensional accuracy.
• Durability: Made of high-quality brass, these probes offer good elasticity and a long service life.
• Reliable connection: The spring-loaded design ensures a consistent and stable electrical connection during testing.
