PA02-Q1 Pogo Pin
PA02-Q1 Pogo Pin
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
Pogo Pin PA02-Q1 Spring Test Probe
Gold plated Tip Test Probe PA02-Q1 Spring Test Probe, PA02-Q1 Test pin PA02-Q1 Test tool Needle gold tip
The PA02-Q1 is a spring-loaded test probe with a four-jaw "plum blossom" head, also commonly referred to as a pogo pin. It is used for making reliable electrical contact with components on printed circuit boards (PCBs) and other electronic assemblies for testing purposes.
Primary applications
Pogo pins like the PA02-Q1 are ideal for manufacturing and testing environments because they are designed for repeated connections and disconnections. Their main uses include:
- PCB testing: Used in a test fixture to rapidly check the electrical properties of a circuit board during production.
- Device programming: Employed in programming jigs to flash firmware onto a board without the need for a permanently soldered header.
- Temporary connections: Useful for debugging, prototyping, and other applications that require a temporary, but reliable, electrical contact.
General pogo pin construction
The PA02-Q1, like most pogo pins, consists of three main components:
- Plunger: The part of the pin that extends and makes contact with the target.
- Barrel: The housing that holds the other components.
- Spring: The component that provides the compressive force to create a reliable electrical connection.
