Spring Test Probe Cup-Shaped Head PA100-A2 Pogo Pin

PA100-A2 gold-plated Spring Test Needle Test Pin, Cup-Shaped head test pin PA100-A2 Pogo Pin

The PA100-A2 is a series of spring test probes, also known as pogo pins, used for making temporary electrical connections in circuit board testing. The "A2" designation refers to the head shape of the pin, which is a cup shaped head.

Specifications

• Head Type: Cup-head
• Head Diameter: 1.5 mm
• Needle Tube Outer Diameter: 1.36 mm
• Total Length: 33.35 mm
• Current Rating: 3A
• Contact Resistance: 50 mΩ
• Spring Force: 180 g
• Recommended Mounting Hole Size: 1.7 mm
