Spring Test Probe Concave Head Tip PA100-A3 Pogo Pin

PA100-A3 gold-plated Spring Test Needle Test Pin, Concave Head Tip test pin PA100-A3 Pogo Pin

The PA100-A3 pogo pin is a specific type of spring-loaded test probe designed for creating temporary electrical connections, particularly for testing printed circuit boards (PCBs). It features a concave head and gold plating for superior conductivity and corrosion resistance.

Specifications

• Model: PA100-A3
• Tip type: Concave head
• Head diameter: 1.8 mm
• Current rating: 3A
• Total length: 33.35 mm
• Full stroke: 6.5 mm
• Materials: Plunger is made of heat-treated beryllium copper, and the barrel is phosphor bronze. Both are gold-plated.
