Spring Test Probe Crown Head PA100-H3 Pogo Pin
PA100-H3 gold-plated Spring Test Needle Test Pin, Nine-claw plum blossom head test pin PA100-H3 Pogo Pin
The PA100-H3 is a type of spring test probe, also known as a pogo pin, that is designed for testing printed circuit boards (PCBs) and other electronic components. It features a 9-claw plum blossom head shape for making secure and stable electrical contact.
PA100-H3 specifications
| Specifications | PA100-H3 Test Probe |
|---|---|
| Head shape | 9-claw plum blossom head |
| Total length | 33.35mm |
| Needle sleeve diameter | 1.36mm |
| Needle head diameter | 1.80mm |
| Spring force | 200g |
| Current rating | 3A |
| Contact resistance | 50mΩ |
| Materials | Barrel: Phosphor brass, gold plated; Plunger: Heat-treated beryllium copper |
Applications
The PA100-H3 probe and others in the PA100 series are used for various electrical testing applications, including:
- PCB testing: Used in in-circuit tests (ICT) and functional circuit tests (FCT).
- Troubleshooting: For diagnosing motherboard failures and other electronic component issues.
- Prototypes and manufacturing: Used in test fixtures to ensure quality control during the production of electronic devices.
