Spring Test Probe Crown Head PA100-H4 Pogo Pin

PA100-H4 gold-plated Spring Test Needle Test Pin, Nine-claw plum blossom head test pin PA100-H4 Pogo Pin

The PA100-H4 is a 9-claw, plum blossom-headed pogo pin primarily used for testing circuit boards. It is a spring-loaded test probe designed to provide a secure and reliable electrical connection during testing. The pin is part of the P100 series of pogo test pins.

Specifications

• Total length: 33.35mm
• Needle sleeve diameter: 1.36mm
• Needle head diameter: 2.0mm
• Head shape: 9-claw plum blossom head
• Materials: Phosphor brass, gold plated
• Usage: For testing circuit boards
• Receptacle: Uses receptacles from the R100 series (e.g., R100-1W) for replacement and easier use.
