PA100-H5 Spring Test Probe
PA100-H5 Spring Test Probe
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
Spring Test Probe Multi-claw Head PA100-H5 Pogo Pin
PA100-H5 gold-plated Spring Test Needle Test Pin, 21-claw Plum Blossom Head test pin PA100-H5 Pogo Pin
The PA100-H5 is a specific type of pogo pin, also known as a spring test probe, that is often used for testing circuit boards and electrical connections. It has a 21-claw plum blossom head.
Specifications
- Total Length: 33.35mm
- Plunger Diameter: 2.50mm
- Pin/Probe Diameter: 1.36mm
- Full Stroke: 6.50mm
- Spring Pressure: 180g
- Current Rating: 3A
- Current Resistance: 50mΩ
- Plunger Material: Heat-treated beryllium copper, gold plated
- Barrel Material: Phosphor bronze, gold plated
- Spring Material: Music wire, gold plated
- Head Shape: 21-claw plum blossom head
How to use a spring test probe
Test probes like the PA100-H5 are meant to be inserted into a receptacle, which is then wired to a testing instrument. This design allows you to easily replace a worn or damaged probe without having to rewire the entire test station. The plum blossom head is designed to grip onto through-holes, solder pads, or component legs on a circuit board to provide a secure and stable connection.
