Spring Test Probe 9-claw Head PA100-H6 Pogo Pin

PA100-H6 gold-plated Spring Test Needle Test Pin, Nine-claw plum blossom head test pin PA100-H6 Pogo Pin

The PA100-H6 is a specific model of spring test probe, also known as a pogo pin, that features a 9-claw "plum blossom" head for establishing electrical contact during circuit board testing. It is designed for use in automated test stations and quality control applications in electronics manufacturing.

Specifications

• Head Style: 9-claw plum blossom head.
• Head Diameter: 3.0mm.
• Total Length: 33.35mm.
• Body Diameter: 1.36mm.
• Materials: Phosphor brass with gold plating.
