Spring Test Probe Four-claw Head PA100-Q1 Pogo Pin

PA100-Q1 gold-plated Spring Test Needle Test Pin, four-claw plum blossom head test pin PA100-Q1 Pogo Pin

The PA100-Q1 is a gold-plated spring test probe used for conductive testing on printed circuit boards (PCBs). The "Q1" in the model number refers to its specific plunger tip style, which has a four-claw or "plum blossom" shape.

Specifications

• Total length: 33.35mm
• Needle outer diameter: 1.36mm
• Needle tip diameter: 0.99mm
• Current rating: 3A
• Current resistance: 50mΩ
• Spring pressure: 180g
• Full stroke: 6.50mm
• Plunger material: Heat-treated beryllium copper
• Barrel material: Gold-plated phosphor bronze
• Spring material: Gold-plated music wire
