Pogo Pin PA125-D/D2 Spring Test Probe

Gold plated Tip Test Probe PA125-D/D2 Pogo Pin PCB test Probe Length 33.35mm Dia 2.02mm Head Dia 2.5m, PA125-D spring test probe PA125-D2 Test pin PA125-D PA125-D2 Test tool 33.35mm 2.02mm Needle gold tip Ø 2.50mm Pogo pin

The PA125-D and PA125-D2 are PCB (Printed Circuit Board) test probes, also known as pogo pins. Spring-loaded contacts used in test fixtures to make reliable electrical connections with test pads or components on a PCB during testing.

• Head type: Round (Large "D" type) head.
• Probe diameter: The needle tube diameter is 2.02 mm.
• Head diameter: 2.5 mm.
• Total length: The probe has an overall length of about 33.35 mm.
• Material: Constructed from durable materials such as brass, often with a gold-plated finish for enhanced conductivity and corrosion resistance.
• Application: Essential for functional and in-circuit testing (ICT) of PCB assemblies. The large round head is well-suited for probing through-hole components or large-area test points.
