Pogo Pin PA125-H2 Test Probe

Gold plated Tip Test Probe PA125-H2 Pogo Pin PCB test Probe Length 33.35mm Dia 2.02mm Head Dia 2.5m, PA125-H2 spring test probe PA125-H2 Test pin PA125-H2 Test tool 33.35mm 2.02mm Needle gold tip Ø 2.50mm Pogo pin

The PA125-H2 is a specific model of spring-loaded test probe, also known as a pogo pin, used for testing printed circuit boards (PCBs) and other electronic components. It is characterized by its "H2" tip, which is a nine-claw, or serrated plum-head, design.

• Total length: 33.35 mm.
• Needle tube outer diameter: 2.02 mm.
• Head diameter: 2.5 mm.
• Tip type: Nine-claw or serrated plum-head design, which is effective for making contact with specific types of terminals, wire wraps, and solder pads.
• Mounting hole size: 2.4 mm.
• Construction: Gold-plated brass or phosphor brass.
