Pogo Pin PA125-J1 Test Probe

Gold plated Tip Test Probe PA125-J1 Pogo Pin PCB test Probe Length 33.35mm Dia 2.02mm Head Dia 1.7mm, PA125-J1 spring test probe PA125-J1 Test pin PA125-J1 Test tool 33.35mm 2.02mm Needle gold tip Ø 1.7mm Pogo pin

The PA125-J1 is a small, round-head spring test probe (also known as a pogo pin) used for creating temporary electrical connections during the testing of printed circuit boards (PCBs).

• Probe tip: The "J" series features a rounded or bullet-nosed tip, designed for contacting pads, points, and fingers without leaving marks. It is suitable for probing flat or sensitive surfaces.
• Dimensions:
  • Needle diameter (tip): 1.70 mm.
  • Barrel/outer diameter: 2.02 mm.
  • Total needle length: 33.35 mm.

Materials: The probe is made from brass with gold plating.
