Gold Plated Spring Test Probe PA160-D3 Pogo Pin
Gold Plated Pogo Pin PA160-D3 Enlarged Round Head Probe Spring Test Probe Tip Dia 1.8mm Pin Length 24.5mm ...
The PA160-D3 is a gold-plated spring test probe used for testing printed circuit boards (PCBs) and other electronic components. It is identified by its specific plunger head style.
PA160-D3 specifications
- Total length: 24.5mm.
- Needle tube outer diameter: 1.36mm.
- Head type: The "D" in PA160-D3 signifies a concave or bowl-shaped head. The D3 is an updated or specific variation within this head style.
- Gold tip diameter: 1.8mm.
- Material: Generally made of brass with a gold-plated exterior.
- Use case: Typically used in test fixtures and receptacles for making contact with electronic components.
Variations in the PA160 series
The PA160 series includes different plunger head types, which are indicated by the letter following the model number. This allows engineers to select the best probe for the specific size and shape of the test points on a PCB.
- PA160-A series: Features a spear-point or conical head.
- PA160-B series: Has a pointed head.
- PA160-E series: Has a conical head.
- PA160-D series: Has a concave or bowl-shaped head, as seen in the D3 model.
