Gold Plated Spring Test Probe PA160-E4 Pogo Pin

Gold Plated Pogo Pin PA160-E4 Large Conical Tip Probe Spring Test Needle 2.0MM Head

The PA160-E4 Pogo Pin is a precision-engineered electrical connector designed for reliable temporary contacts in testing and assembly applications. Crafted to maintain consistent conductivity, it ensures stable signal transmission and rapid electrical connections. Its robust spring mechanism offers durability and excellent compliance, making it ideal for high-frequency and high-density environments. This component enhances operational efficiency by providing secure yet easily detachable connections, suitable for automated testing systems and modular electronic assemblies.

• Model: PA160-E4
• Needle diameter (tip): 2.0mm.
• Total length: 24.5mm.
• Barrel diameter: 1.36mm.
• Full stroke: 4.0mm.
• Spring pressure: 140 grams (at full stroke).
• Current rating: 3A.
• Current resistance: 50 milliohms.
• Materials:
  • Plunger (needle): Heat-treated beryllium copper.
  • Barrel: Phosphor bronze, gold-plated.
  • Spring: Music wire, gold-plated.
