Gold Plated Flat-head Spring Test Probe PA160-G2 Pogo Pin

Gold Plated Pogo Pin PA160-G2 Flat-head Tip Probe Spring Test Needle Tube Outer Diameter 1.36MM, PA160-G2 test needle head 1.5mm gold-plated tip total length 24.5mm ...

The PA160-G2 is a flat-head spring test probe (also known as a pogo pin) used for testing printed circuit boards (PCBs) and other electronic components. It features a spring-loaded design that provides reliable contact with test points without requiring soldering.

• Model: PA160-G2
• Head Style: Flat head
• Total Length: 24.5 mm
• Barrel Diameter: 1.36 mm
• Head Diameter: 1.5 mm
• Drilling Size: 1.70–1.75 mm
• Minimum Test Distance: 2.54 mm
• Rated Current: 3A
• Contact Resistance: 50mΩ
• Stroke: 4.0 mm
• Materials: Brass with a gold-plated tip.

• PCB testing: Accessing test pads and component leads on a PCB.
• Automated test equipment (ATE): Use in fixtures and test jigs for high-volume production testing.
• Programming: Temporarily connecting to programming headers without permanent soldering.
• Quality assurance: Testing for electrical continuity and defects in manufacturing.
