Gold Plated Spring Test Probe PA160-H2 Nine Claw Plum Blossom Head Pogo Pin

Gold Plated Pogo Pin PA160-H2 Nine Claw Plum Blossom Head Tip Probe Spring Test Needle Tube Outer Diameter 1.36MM, PA160-H2 test needle plum head 1.5mm gold-plated tip total length 24.5mm ...

The PA160-H2 is a gold-plated spring test probe (also known as a pogo pin) primarily used for testing printed circuit boards (PCBs) and other electrical components. It is part of the P160 series of probes.

• Head shape: 9-claw plum blossom head, designed for a secure grip on test points.
• Total length: 24.5 mm.
• Barrel diameter: 1.36 mm.
• Full stroke: 4.0 mm.
• Spring pressure: 140 g.
• Current rating: 3A.
• Current resistance: 50 mΩ.
• Materials:
  • Plunger: Heat-treated beryllium copper.
  • Barrel: Gold-plated phosphor bronze.
  • Spring: Gold-plated music wire.

• Durable and reliable: The gold-plated contacts and quality materials ensure superior conductivity and a long service life.
• Secure contact: The 9-claw plum blossom tip provides a strong, reliable connection to prevent slippage during testing.
• Easy to use: The spring-loaded design allows for quick and easy placement and removal, making the testing process more efficient.
• Versatile applications: It is commonly used in testing jigs and fixtures for production and quality control.
• Replacement part: The PA160-H2 and its associated receptacle are designed to allow for easy probe replacement if damaged or worn, extending the life of the test station.
