Gold Plated Spring Test Probe PA160-J1 Straight Round Head PCB Pogo Pin
Spring Test Probe PA160-J1 straight round head PCB pogo pin Test Pin Test Tool 10mm outer diameter 1.36mm Needle Gold Tip Dia 0.99mm
The PA160-J1 is a small, gold-plated spring test probe used primarily for testing printed circuit boards (PCBs). It is a type of pogo pin that features a straight, round head designed for making solid contact with a test pad. The "PA160" part of the model number indicates its series, while "J1" specifies its head style.
Key specifications
- Head/Tip style: Small, straight, and rounded.
- Needle outer diameter: 1.36 mm.
- Needle diameter: 0.99 mm.
- Needle total length: 24.5 mm.
- Drilling size: 1.7 mm.
- Material: Gold-plated brass for high conductivity.
- Automated Testing Equipment (ATE): Mounted in a test fixture, the spring-loaded probe makes temporary but reliable contact with specific points on a PCB for electrical testing.
- In-Circuit Testing (ICT): The probes access individual components on a printed circuit assembly to test for shorts, opens, resistance, capacitance, and other basic functions.
- PCB Prototyping and Debugging: The probes can be used to quickly access test points on a prototype circuit board during the development phase.
