Gold Plated Spring Test Probe PA50-E2 Conical Tip Pogo Pin

The PA50-E2 Pogo Pin is a spring-loaded test probe widely used for PCB testing, programming, and creating temporary electrical connections in jigs. It features a conical tip for making contact with test pads and component holes.

Specifications

• Model: PA50-E2
• Head Type: Conical head
• Total Length: 16.5 mm
• Barrel Diameter: 0.68 mm
• Needle Rod Diameter: 0.48 mm
• Tip Diameter: 0.9 mm
• Full Stroke: 2.65 mm
• Spring Pressure: 75–100 g
• Current Rating: 3A
• Current Resistance: 50mΩ
• Mount Type: DIP/receptacle
• Minimum Test Spacing: 1.27 mm
• Materials: Gold-plated brass with a stainless steel plunger
