Spring Test Probe PA50-G2 Pogo Pin

The PA50-G2 spring test probe is a type of pogo pin with a gold needle tip, commonly used for testing printed circuit boards (PCBs) and other electronic components. It is designed for applications where a temporary, but reliable, electrical connection is required.

Key specifications

• Needle tip diameter: 0.9 mm
• Pin body diameter: 0.68 mm
• Overall length: 16.55 mm
• Tip type: Gold needle tip ("G" indicates a gold-plated needle)
• Load type: Compression
• DIY supplies: Electrical
