Gold Plated Spring Test Probe PA50-Q1 4-point Crown tip Pogo Pin
The PA50-Q1 is a spring-loaded test probe (also known as a pogo pin) with a crown-shaped tip, designed for testing circuit boards. The Q1 tip has four points and is best suited for contacting solder joints and pads. These probes are typically gold-plated to ensure better contact performance.
Key specifications
| Specification | Details | |
|---|---|---|
| Model | PA50-Q1 | |
| Tip type | 4-point crown head | |
| Material | Plunger: Heat Treated Beryllium Copper Barrel: Phosphor Bronze (Gold Plated) Spring: Music Wire (Gold Plated) |
|
| Total length | 16.55mm | |
| Needle tube diameter | 0.68mm | |
| Needle diameter | 0.48mm | |
| Spring pressure | 75g (at full stroke) | |
| Full stroke | 2.65mm | |
| Current rating | 3A | |
| Current resistance | 50mΩ | |
| Recommended minimum spacing | 1.27mm (between test points) |
Common uses
- Printed Circuit Board (PCB) testing: PA50-Q1 probes are essential for accessing and testing components on printed circuit assemblies.
- Functional testing: They are used to perform conductive and functional tests, checking for stability and durability.
- Data communication equipment: The probes are widely used in data communication equipment, receptacles, and wire wraps.
