PA9021 ifm Pressure Sensor

PA9021 ifm Pressure Sensor
Core Specifications

• Measuring Range: 0 to 250 bar (0 to 3625 psi) relative pressure.
• Output Signal: Precise linear 0 to 10 V analogue signal.
• Operating Voltage: 16 to 32 V DC.
• Connection: M12 connector (4-pin) with gold-plated contacts.
• Process Connection: G 1/4 internal thread.
• Materials:
  • Housing: Stainless steel (316L / 1.4404).
  • Wetted Parts: Stainless steel (303 / 1.4305), ceramics, and FKM (Viton).
• Protection Rating: IP 68 / IP 69K for high environmental resistance.
• Temperature Range: -25 to 90 °C medium temperature (expandable to -40 °C on request).

Key Features

• Durability: Tested for over 100 million pressure cycles with high overload protection (up to 400 bar).
• Precision: High repeatability and low linearity error for consistent performance.
• Safety: Includes reverse polarity and overload protection.
• Media Compatibility: Suitable for liquids and gases (use in gases > 25 bar only on request).
