Spring Test Probe PAL50-D2 Dome-shaped Head Pogo Pin

Test Tool PAL50-D2 Spring Test Pin Gold Plated Needle Rounded Head 0.9mm

The PAL50-D2 is a specific model of spring test probe, also known as a pogo pin, used for testing printed circuit boards (PCBs) and other electronic components. The D2 designation indicates it has a rounded or dome-shaped head.

Technical specifications

• Head type: D-head (round or dome-shaped)
• Needle diameter (tip): 0.68mm
• Needle Tip outer diameter: 0.9mm
• Overall length: 27.8mm
• Pitch: 1.27mm
• Rated current: 3A
• Contact resistance: 50mΩ
• Material: Copper, with a gold finish
