Gold Plated Spring Test Probe PAL50-J1 Pogo Pin

Gold-plated straight round needle 0.68MM test probe

The P50-J1 is a spring test probe, also known as a pogo pin, used for electrical testing of printed circuit boards (PCBs).

Specifications

• Current rating: 3A
• Resistance: 50mΩ
• Stroke: 2.6mm
• Probe tube diameter: 0.68mm
• Probe rod diameter: 0.48mm
• Tip shape: Round head
• Materials: Gold-plated phosphor bronze body, heat-treated beryllium copper piston, and a gold-plated spring
