PAL75-A2 Pogo Pin
PAL75-A2 Pogo Pin
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
Spring loaded test probe PAL75-A2 test pin
Gold plated Spring test needle PAL75-A2 Pogo Pin outer diameter 1.02mm total length 33.35mm for testing
The PAL75-A2 pogo pin is a spring-loaded test probe used to create temporary electrical connections.
Specifications
- Total length: 33.35mm.
- Body diameter: The main body of the pin is about 1.02mm in diameter.
- Head diameter: The contact tip has a diameter of 1.3mm.
- Material and finish: Phosphor bronze barrel and a gold-plated beryllium copper plunger.
- Spring force: The pressure required to compress the pin is typically around 100g to 180g.
- Current rating: It is rated for a maximum current of 3A
Applications
Pogo pins like the PAL75-A2 are essential components in electronics manufacturing and testing. Their spring mechanism allows them to accommodate slight misalignments and vibrations while maintaining a solid electrical connection. Common uses include:
- Test jigs: Creating reliable connections for functional testing of printed circuit boards (PCBs).
- Programming: Connecting programmers for JTAG or SWD programming on boards where solder points are not practical.
- Charging: Providing a charging interface for compact electronic devices, often featuring a magnetic connection.
- Prototyping: Making quick, non-permanent contacts for development and prototyping purposes.
