Gold Plated Spring Test Probe PAL75-D2 Pogo Pin

Gold Plated Pogo Pin PAL75-D2 Spring Test Probe Test Pin Dia 1.02mm Pin Length 33.35mm for Testing, Round Tip Probe PAL75-D2 Test Needle Gold Plated ...

The PAL75-D2 is a spring-loaded test probe used for making temporary electrical connections, primarily for testing printed circuit boards (PCBs).

Key specifications

• Head type: The "D2" designation typically refers to a rounded or spherical head.
• Diameter: The pin has a diameter of 1.02 mm.
• Length: A total length 33.35 mm.
• Current rating: 3 amps.
• Materials: Gold-plated materials, such as a phosphor bronze barrel and a beryllium copper plunger, for good conductivity and corrosion resistance.

• Perform quick and accurate functional tests on PCBs.
• Program and debug boards without permanently soldering header pins.
• Check for shorts, open circuits, and other defects in a circuit.
