Gold-plated Spring Test Pin PAL75-F1 Pointed Four-claw Test Needle
Gold plated Spring Test Probe PAL75-F1 33.35mm 1.02mm Gold Needle Tip 0.74mm Pogo Pin PL75-F, Test Pin PAL75-F1 Pointed Four-claw Length 33.35mm Outer Diameter 1.02m for Circuit Board Testing
The PAL75-F1 is a type of pogo pin, also known as a spring test probe, commonly used for making temporary electrical connections, particularly in circuit board testing and various other applications like mobile devices, medical equipment, and automotive electronics.
| Specifications | Value |
|---|---|
| Model | PAL75-F1 |
| Needle tube outer diameter | 1.02mm |
| Needle diameter | 0.74mm |
| Total needle length | 33.35mm |
| Recommended Drilling Size | 1.4mm |
| Material | Gold-plated copper |
| Current Rating | 3A |
| Spring Force | 120g |
| Contact Resistance | 50mΩ |
| Barrel Material | Phosphor Bronze |
| Plunger Material | Heat Treated Beryllium Copper |
| Spring Material | Music Wire |
