Spring Test Probe Thimble PAL75-G2 Test Needle

Pogo Pin PAL75-G2 Spring Test Probe PAL75-G Test Pin Test Tool Length 33.35mm Dia1.02mm

The PAL75-G2 pogo pin is a spring test probe used for establishing a temporary electrical connection in electronics testing.

• Model: PAL75-G2
• Total Length: 33.35mm
• Outer Diameter (Shank): 1.02mm
• Needle Head Diameter: 1.30mm
• Materials: Gold-plated brass to ensure a long lifespan and a low contact resistance.

• PCB Testing: The primary use for pogo pins like the PAL75-G2 is in automated testing of populated PCBs to check for electrical continuity, shorts, and other defects.
• Test Fixtures: These pins are essential components of test jigs and fixtures, which are used to hold a PCB in place and make contact with specific test points.
• Programming and Firmware: The pins can also be used to make temporary connections to programming or debug ports on a board, such as JTAG or SWD.
• Temporary Connections: Their spring-loaded nature allows for quick, repetitive, and reliable connections to be made without soldering.
