Gold Plated Spring Test Probe PAL75-H2 Pogo Pin
Gold Plated Pogo Pin PAL75-H2 Spring Test Probe Dia 1.02mm Pin Length 33.35mm for Testing,
The PAL75-H2 is a type of pogo pin, which is a spring-loaded test probe used to make temporary electrical connections during PCB (printed circuit board) testing. The "H2" in the model name specifies the particular tip style and size.
Key specifications
- Head type: Plum Blossom (sometimes described as Serrated).
- Overall length: 33.35mm.
- Needle (plunger) diameter: 1.3mm.
- Barrel (needle tube) outer diameter: 1.02mm.
- Drill size for mounting: 1.4mm.
- Material: Gold-plated copper or brass.
- Application: Ideal for production line testing jigs and fixtures for PCBs.
How pogo pins work
Pogo pins consist of a barrel, a plunger, and a spring. The spring-loaded design allows the pin to compress when pressed against a surface, creating a reliable electrical connection. The spring force and tip style are chosen based on the specific testing requirements.
Usage
- Programming and testing jigs: For programming microcontrollers or testing PCBs without having to solder headers onto the board.
- In-circuit testing (ICT): To verify a finished PCB for shorts, opens, and component values.
- Temporary electrical connections: For any application requiring a temporary but robust connection, such as charging docks or battery contacts.
