Spring Test Probe PAM75-B1 Pogo Pin

Gold Plated Test Probe PAM75-B1 Test Needle Brass Test Probe Sleeve Length 27.8mm Convenient Gold Plated Test Tool

The PAM75-B1 pogo pin is a spring-loaded test probe widely used for making temporary but reliable electrical connections during the testing or programming of printed circuit boards (PCBs). It features a flexible needle tip designed for precise contact with test pads and holes.

Product specifications

• Model: PAM75-B1
• Head type: Flexible needle (sometimes referred to as a "spear" or "cusp spear" head)
• Total length: 27.8mm
• Barrel diameter: 1.02mm
• Plunger diameter: 0.74mm
• Spring pressure: Approximately 100g
• Current rating: 2A to 3A
• Full stroke: 3mm
• Materials: Gold-plated phosphor bronze barrel and heat-treated copper plunger
• Color: Gold
