Spring test probe PAM75-D2 Pogo Pin
Gold plated spring test needle PAM75-D2 test pin test tool, PM75-D2 Testing pin length 27.8mm Dia 1.02mm
The PAM75-D2 is a model number for a pogo pin, also known as a spring-loaded test probe, used for testing printed circuit boards (PCBs) and other electronic components.
Key specifications
- Total length: 27.8 mm.
- Diameter: 1.02 mm.
- Pin tip: The "D2" in the part number indicates a specific tip style. It features a round or spherical head, designed to make reliable contact with a PCB's test pads without leaving marks.
- Compatibility: A matching receptacle (the housing that holds the pogo pin) is available under the part number P75-3W.
Usage and features
Pogo pins are commonly used in custom-made programming and testing jigs in production environments. Their spring-loaded nature allows them to create a solid, temporary electrical connection to a test point on a device.
- Accuracy: The pins are manufactured for precision testing of PCBs.
- Durability: The pin is designed to provide reliable contact over many cycles of compression and release.
- Versatility: The design is well-suited for applications where quick and repeatable connections are necessary during manufacturing or quality control.
