Spring Test Probe 4-point Crown Head PAM75-Q2 Pogo Pin

Test Probe PAM75-Q2 large four-claw probe 1.02 mm test needle test probe spring thimble PAM75Q2

The PAM75-Q2 pogo pin is a specific model of spring-loaded test probe designed for testing printed circuit boards (PCBs) and other electronic components. It is identified by its crown-shaped contact head (Q2) and standard diameter (75).

Key specifications

  • Model number: PAM75-Q2
  • Head type: 4-point crown head (Q2)
  • Materials: Gold-plated plunger (heat-treated beryllium copper), barrel (phosphor bronze), and spring (music wire)
  • Needle sleeve diameter: 1.02 mm
  • Needle total length: 27.8 mm
  • Current rating: Up to 3A
  • Current resistance: 50 mΩ
  • Spring pressure: Typically 100g, though customizable options may be available
  • Full stroke: 2.50 to 2.65 mm
Common applications
Pogo pins like the PAM75-Q2 are crucial components in the electronics industry. Their spring-loaded, resilient design ensures a stable electrical connection, even with repeated use.
  • PCB testing: Used in test fixtures and jigs to make electrical contact with pads and component feet on circuit boards for diagnostics and quality control.
  • Board-to-board interconnects: Ideal for creating modular or temporary connections between circuit boards.
  • Charging applications: Used in charging ports for smaller electronic devices like smartwatches, fitness trackers, and other wearables.
  • Industrial use: Deployed in industrial equipment to reduce wiring complexity and provide robust connections.
