PFX07-179 Electronic expansion valve (EEV) coil

PFX07-179 Electronic expansion valve (EEV) coil
Key Functions

• Component Protection: Keeps component carrier tape securely aligned during high-speed pick-and-place movements.
• Peel-Off Stability: Assists the feeder mechanism in smoothly stripping away the top cover tape film.
• Spillage Prevention: Prevents tiny Surface Mount Devices (SMDs) from dislodging or jumping out of the embossed tape pockets before the vacuum nozzle picks them up. [1, 2]

Purpose & Application

• What it does: The coil slips over the physical body of an electronic expansion valve. When the HVAC main board drives it with electrical pulses, it creates a magnetic field that steps an internal needle open or closed.
• Function: This action precisely regulates the flow of refrigerant entering the evaporator, ensuring optimal cooling efficiency and precise temperature control.
