PHS-12EC-R SMT GEAR ,PHS-12ECL SMT GEAR

PHS-12EC-R SMT GEAR ,PHS-12ECL SMT GEAR
Quick Specifications for PHS-12EC

• Bore Diameter (d): 12 mm
• Thread Size (G): M12 × 1.75
• Thread Length (l₃): 24 mm
• Overall Length (l₄): 65 mm
• Static Load Rating (C₀): 13.7 kN
• Dynamic Load Rating (C): 26.2 kN
• Lining Material: Maintenance-free PTFE (often lubrication-free)

Common ApplicationsThese spherical plain rod ends are used heavily in industrial automation, robotics, conveyor systems, and machine tool linkages to manage oscillating movement and compensate for misalignments. If you would like, let me know:

• Is this for an SMT placement machine, motorcycle/automotive shift linkage, or general machinery?
• Are you looking for replacement parts, dimensional drawings, or an exact quote?

I can help you narrow down the exact component you need!
