Pisco Vacuum Filter VFU2-66P
Pisco Vacuum Filter VFU2-66P
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
Pisco Vacuum Line Filter VFU2-66P
VFU Series Vacuum Filter VFU2-66P Union Type, PISCO Vacuum Filter Small Union Resin Type 7.5cm VFU2-66P
The VFU2-66P vacuum filter is an in-line, small union type filter manufactured by PISCO for industrial vacuum systems, designed to remove dust with a filtration level of 5μm. It helps lengthen the work life of vacuum pumps by preventing dust and water droplets from entering.
Specifications
| Manufacturer | PISCO Co. Ltd |
| Type | Small Union Type Vacuum Filter |
| Application | Industrial vacuum lines |
| Filtered Matter | Dust |
| Filtration Level | 5μm (Collection efficiency: 95%) |
| Connection Type | One-Touch Pipe (mm Size) |
| Connection Tube Dia. | Ø6 mm (both inlet and outlet) |
| Filtration Area | 7.5 cm² |
| Operating Fluid | Air |
| Working Pressure Range | -100 kPa to 0 kPa |
| Operating Temp. Range | 0°C to 60°C (without freezing) |
| Body Material | Brass + Electroless nickel plating + PBT resin |
| Filter Material | Polyvinyl formal (PVF) |
| Seal Material | Nitrile rubber (NBR) |
| Weight | 19 g |
