PKWS4M-5/TXL Proximity sensor

PKWS4M-5/TXL Proximity sensor
Technical Specifications

• Connector End A: Female M8 × 1, angled, 4-pin with gold-plated contacts.
• Connector End B: Flying leads (open ended wire).
• Cable Length: 5 metres.
• Jacket Material: Premium Polyurethane (PUR) in black color.
• Core Cross-Section: 4 × 0.34 mm².
• Electrical Ratings: 50 VAC / 60 VDC, up to 4 A current capacity.
• Ingress Protection: Certified IP67 and IP69K for harsh, wet, or washdown industrial environments.

Key Performance Benefits

• Drag Chain Compatible: Highly flexible design tested for over 5 million bending cycles, making it ideal for moving machinery.
• Environmental Resistance: Highly resilient against welding sparks, chemicals, UV radiation, and oils.
• Safety & Hazard Free: Flame-retardant and free from halogen, silicone, PVC, and LABS.
