FOTEK PL-05N Inductive Proximity Sensor
PL-05N NPN NO Inductive Proximity Sensor DC10-30V SN-5mm Fotek, PL-05N Sensor 5 mm Sensing Distance, NPN Normally Open (NO) Output
The FOTEK PL-05N is a square, flush-mounted inductive proximity sensor with a 5 mm sensing distance and an NPN normally open (NO) output. It operates on a 10-30V DC power supply and is widely used in industrial automation due to its reliability and compact size.
Specifications
| Sensing Distance | 5 mm |
| Output Method | NPN, Normally Open (NO) |
| Operating Voltage | 10-30V DC |
| Response Frequency | Up to 800 Hz |
| Load Current | ≤ 150 mA |
| Protection Degree | IP67 (dust and water resistant) |
| Operating Temperature | -20°C to +80°C (-4°F to +176°F) |
| Body Material | High-impact plastic (ABS resin) |
| Body Dimensions | 35 x 17 x 17 mm (L x W x T) |
| Wiring | 3-wire DC (Brown: +V, Blue: 0V, Black: Out signal) |
| Mounting | Flush |
Applications
The FOTEK PL-05N is a versatile component primarily used in industrial settings.
- Industrial Automation: Used for detecting the presence and position of metal components in production lines.
- Machinery & Robotics: Integrated into machine tools for positioning control and object detection in robotics.
- Manufacturing Systems: Ideal for use on conveyor systems and CNC equipment.
- General Control Systems: Used widely for counting objects, limiting travel, and general contactless switching due to its reliability and ruggedness.
